The main image shows the finished layout: one upright spiral-guide cassette sits on each side column near the upper corners. The workshop photo below shows the guide assemblies in production. Opening dimensions, clearances, controls and performance are confirmed against the project's drawings and operating needs.
The visible spiral-guide cassettes sit vertically on the left and right side columns near the upper corners of the opening. The opening size, available headroom, side structure, door leaf and operating path must be checked together before fabrication.
Share the traffic type, peak movements and expected operating schedule. The drive and controls are selected for the actual use rather than an assumed cycle rating.
Forklift approach, pedestrian crossings, visibility and available space around the upper beam and side structures affect the layout and safety package.
For UAE or Saudi sites, state whether the opening is internal or external and describe heat, dust, wind or coastal exposure. Suitability is reviewed for the specific configuration.
Because the spiral-guide cassettes are mounted on the side columns near the upper corners, the available side room, headroom, drive-bar arrangement and surrounding structure should be checked from the actual elevation. Please send drawings or photographs rather than relying on a generic size.
Opening speed, duty cycle, materials, controls, safety package and wind or environmental performance are not assumed from the product name; they are confirmed in the project quotation.
Compare all high-speed door systemsIn the configuration shown here, the spiral-guide cassettes are upright on the left and right side columns near the upper corners. The final arrangement must be verified from the approved drawing.
Material and construction depend on the selected door-leaf specification and must be confirmed in the technical documents for the order.
These values depend on the selected drive, dimensions and control system. We confirm the quoted performance for the specific configuration; no generic value is assumed here.
Send the opening dimensions, elevation, headroom and side room, traffic pattern, expected cycles, destination and quantity.
Include the elevation, clear opening, upper-beam space, traffic pattern and destination so we can review the head layout before quoting.
